Model | ZL38-04 | |||||||
Working Voltage Range | DC: 6V-24V | |||||||
Rating Power | 6V: 0-21W / 12V: 0-21W / 24V: 0-28W | |||||||
Static Water Head | 0-7 M | |||||||
Static Flow Rate | 0-9 L/min | |||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000Hr | |||||||
Working Environment | Liquid: From weak acid to weak base, workable on land (Non submersible) | |||||||
Max Noise | Under normal working status, 1M distance over test instrument <40dB | |||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤70℃ | |||||||
Application | Water coolant of computer, small fountain, aquarium, etc. | |||||||
Size | IP Grade | Inlet | Outlet | Remark | ||||
Length（mm） | Width（mm） | Height（mm） | OD（mm） | ID（mm） | OD（mm） | ID（mm） | Inlet and outlet have twist lock | |
54 | 46 | 96 | IP67 | φ18 | φ13.0 | φ18 | φ5 | |
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
