Model | ZL38-18 | ||||||||
Working Voltage Range | DC: 6V-24V | ||||||||
Rating Power | 6V: 0-14W / 12V: 0-14W / 24V: 0-20W | ||||||||
Static Water Head | 0-6 M | ||||||||
Static Flow Rate | 0-8 L/min | ||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000Hr | ||||||||
Working Environment | Liquid: From weak acid to weak base, workable on land (Non submersible) | ||||||||
Max Noise | Under normal working status, 1M distance over test instrument <36dB | ||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤70℃ | ||||||||
Application | Water heating mattress, Water heating seat cushion, Hot water cycle, etc. | ||||||||
Size | IP Grade | Inlet | Outlet | Remark | |||||
Length（mm） | Width（mm） | Height（mm） | OD（mm） | ID（mm） | OD（mm） | ID（mm） | Inlet and outlet have footgrip | ||
69.5 | 57 | 58.5 | IP67 | φ17 | φ13 | φ9 | φ6 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
