Model | ZL38-06 | ||||||||
Working Voltage Range | DC: 6V-24V | ||||||||
Rating Power | 6V: 0-19W / 12V: 0-19W / 24V: 0-28W | ||||||||
Static Water Head | 0-7 M | ||||||||
Static Flow Rate | 0-9 L/min | ||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000Hr | ||||||||
Working Environment | Liquid: From weak acid to weak base, workable both on land and in water (Submersible) | ||||||||
Max Noise | Under normal working status, 1M distance over test instrument <40dB | ||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤70℃ | ||||||||
Application | Solar water circulation system, water coolant of computer, small fountain, aquarium, etc. | ||||||||
Size | IP Grade | Inlet | Outlet | Remark | |||||
length（mm） | width（mm） | Height（mm） | OD（mm） | ID（mm） | OD（mm） | ID（mm） | Outlet with footgrip | ||
54 | 43 | 96.5 | IP68 | φ17 | φ13.2 | φ11.7 | φ6 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
