| Model | ZL38-09 | ||||||||
| Working Voltage Range | DC：6-24V | ||||||||
| Rating Power | 6V：2-12W / 12V：3-18W / 24V：5-25W | ||||||||
| Static Water Head | 1-6M | ||||||||
| Static flow rate | 4-10Litre / minute | ||||||||
| Lifespan | Continuous operation under normal working condition ≤ 24 hours, service life＞20000hour | ||||||||
| Working Environment | Applicable liquid pH: weak acid, neutral, weak base. Non diving use | ||||||||
| Max Noise | Continuous operation under normal working conditions（The pump is 1M away from the tester）＜40Decibel | ||||||||
| Max Working Temperature | Under normal temperature environment, the temperature of the aqueous medium≤70℃ | ||||||||
| Application | Hot water shower, foot bath, small fountain, aquarium, etc. | ||||||||
| Size | IP Grade | Inlet | Outlet | Remarks | |||||
| Length (mm) | Width (mm) | Height (mm) | OD (inch) | ID (mm) | OD (inch) | ID (mm) | 進(jìn)、Outlet Thread為 正旋Standard threaded pipe | ||
| 102 | 45 | 140.5 | IP67 | G1/2〞standard Thread tube | φ13 | G1/2〞standard Thread tube | φ5 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
